Multitube Hairpin Heat Exchanger
Surface areas for these units range from 1 square foot to 6000 square feet and pressures range from full vacuum to over 14000 psi.
Multitube hairpin heat exchanger. Hairpin heat exchangers use true counter current flow. There is a case that the duty of exchanger is lower than 500 kw and the area required is lower than 300 squered feet. Unlike multi pass shell and tube designs where correction factors are used to account for inefficiencies resulting from co current passes this process maximizes temperature differences between shellside and tubeside fluids. Owing to its fewer sections and less surface area a hairpin heat exchanger is the most efficient design when a process requires a temperature cross hot fluid outlet temperature is below cold fluid outlet temperature.
Hrs produces a range of different multi tube heat exchangers for use in a wide range of different industries and. Hairpin multitube heat exchangers the principle hairpin exchangers are jacketed u tube heat exchangers operating in a true countercurrent flow hot fluid outlet temperature is below the cold fluid outlet temperature resulting in a very energy efficient design. The product flows through the interior tubes and the service fluid flows through the surrounding shell. All hairpin heat exchangers are designed and fabricated to asme and tema standards and client specifications.
The surface area ranges from 1 square foot to 6000 square feet finned tubes. Hairpin heat exchanger specification march 2017 process industry practices page 2 of 13 1. What distinguishes a hairpin exchanger from a traditional shell and tube exchanger are its closures. Dear all as we know there are some rules to use double pipe heat exchanger instead of shell and tube heat exchanger.
Utilizing a 27000 sft facility we can. Sometimes referred to as g fin double pipe or multitube heat exchangers the hairpin heat exchanger has been used in process industries for many years. Is an asme code certified manufacturer offering standard designs as well as custom designs to meet clients specifications. Multi tube hairpin heat exchangers the muti tube hairpin heat exchanger also known as multis take the benefits of both shell and tube heat exchangers and double pipe heat exchangers.
Our hairpin exchangers are available in single tube double pipe or multiple tubes within a hairpin shell multitube bare tubes finned tubes u tubes straight tubes with rod thru capability fixed tube sheets and removable bundle. As the name suggests a multitube heat exchanger uses more than one tube to carry the product. Scope this practice describes the design fabrication examination inspection testing and documentation requirements for double pipe and multitube hairpin type heat exchangers to be. A hairpin heat exchanger can be described as a single pass shell and tube unit that has been folded in half to give it a hairpin appearance.
Putting over 28 years of experience to work for you as one of the largest manufacturers of hairpin heat exchanger lines in the unites states. Multitube hairpin heat exchanger posted in process heat transfer.
